Precise Beam Splitting: Accurate control of reflection and transmission ratios for efficient beam management
High Laser Damage Threshold (LIDT): Suitable for high-power and ultrafast laser applications
Low Absorption & Scattering: Maintains beam quality and reduces optical losses
Excellent Spectral Stability: Reliable performance across the specified wavelength range
High Optical Efficiency: Maximizes energy utilization within the laser system
Superior Surface Flatness: Preserves wavefront quality and system stability
Environmental Durability: Resistant to humidity, temperature variations, and chemical exposure
Customizable T/R Ratios: Available in multiple reflection/transmission configurations (50:50, 80:20, 95:5, etc.)
Wide Wavelength Availability: From UV to Mid-IR and ultra-broadband ranges
Long Service Life: Durable IBS coatings ensure consistent long-term performance
Specifications
Optical Specifications
Wavelength Range: 300 – 2800 nm (model dependent)
Common Wavelengths: 532 nm, 800 nm, 1030 nm, 1064 nm, 1150 nm, 2000 nm, 2940 nm
Transmission / Reflection Ratios:
- 50:50
- 80:20
- 90:10
- 95:5
- 99:1 (customizable)
Angle of Incidence (AOI): 0° or 45° (standard options)
Surface Flatness: < λ/10 @ 633 nm (typical)
Surface Quality: 20-10 Scratch/Dig (typical)
Coating Technology: Ion Beam Sputtering (IBS)
Laser-Induced Damage Threshold (LIDT): > 0.3 J/cm² @ 10 ns (model dependent)
Mechanical Specifications
Standard Dimensions (mm):
- 12.7 x 6.0
- 12.7 x 6.35
- 25.4 x 2.0
- 25.4 x 3.0
- 25.4 x 6.35
- 50.8 x 9.0 (varies by model)
Substrate Material: High-quality optical glass (laser-grade)
Mounting Type: Plate / Plano configuration
Performance Features
- High Reflectivity & Controlled Transmission
- Low Optical Loss
- High Thermal Stability
- Broadband or Narrowband Coating Options
- High Environmental Stability
Applications
- Laser cavity output coupling
- Femtosecond & ultrafast laser systems
- Nd:YAG and Ti:sapphire lasers
- Yb-doped laser systems
- Laser power monitoring and diagnostics
- Spectroscopy and nonlinear optics
- Industrial laser processing
- Medical and scientific research systems
(Custom sizes, coating wavelengths, and T/R ratios are available upon request.)
