Metal-coated mirrors are key reflective components used in a wide range of optical systems, including laser assemblies, analytical instruments, and laboratory experiments. Unlike standard dielectric mirrors, metal-coated plane mirrors offer consistent performance over a very broad spectral range, providing dependable reflection across multiple wavelength bands.

Download Brochure

- +

They can operate from the ultraviolet through the infrared spectrum, with particularly strong performance in the visible, near-infrared (NIR), and mid-infrared (MIR) regions. Typical aluminum- and gold-coated mirrors, for instance, can effectively reflect light from approximately 200 nm to 2500 nm, with reflectivity generally reaching around 98–99% depending on the coating and wavelength.

Due to the intrinsic characteristics of metallic coatings, these mirrors also demonstrate good tolerance to temperature changes and environmental conditions. This results in stable optical performance, long-term durability, and reliable operation even in demanding research and industrial environments, making them a versatile choice for broadband optical applications.

Specifications

Product Code Brand Diameter(mm) Thickness(mm) Wavelength(nm) AOI(°)
663953 WAVEQUANTA 25 6 0 – 5
663954 WAVEQUANTA 12.7 6.35 350 – 2500 0 – 45
663955 WAVEQUANTA 12.7 6.35 600 – 1000 0 – 45
663956 WAVEQUANTA 12.7 6 350 – 2500 0 – 45
663957 WAVEQUANTA 12.7 6 350 – 2500 45
663958 WAVEQUANTA 12.7 4 350 – 2500 0 – 45
663959 WAVEQUANTA 12.7 3 350 – 2500 45
663960 WAVEQUANTA 25.4 6.35 600 – 2000 0 – 5
663961 WAVEQUANTA 25.4 3 350 – 2500 45
663962 WAVEQUANTA 25.4 6 700 – 1050 0 – 45
