Specifications:
Conforms to the specifications of: ASTM D891; D1250, D4052, D5002, D5931;ISO 12185 DIN 51757; IP 365
Measurement Ranges:
Density: 0 to 3 g/cm3
Temperature: 0°C to 100°C (controlled via Peltier)
Pressure: 0 to 10 bars
Measurement Modes: Continuous, Single, Multiple
Measurement Technique: Mechanical Oscillating U-Tube
Measurement Time: 30 to 60 seconds after thermal equilibrium
Accuracy:
K86200: Density: 0.00005 g/cm3
Temperature: 0.02˚C
K86201: Density: 0.0001 g/cm3
Temperature: 0.03˚C
K86250: Density: 0.00001 g/cm3
Temperature: 0.01˚C
Repeatability:
K86200: Density: 0.000005 g/cm3
Temperature: 0.01˚C
K86201: Density: 0.00001 g/cm3
Temperature: 0.02˚C
K86250: Density: 0.000002 g/cm3
Temperature Selectable: 0.001˚C
Resolution:
K86200: Density: 0.00001 g/cm3
Temperature: 0.01 C
K86201: Density: 0.0001 g/cm3
Temperature: 0.01 C
K86250: Density: 0.000001 g/cm3
Temperature: 0.001 C
Minimum Sample Volume: less than 1 ml, approximately
Wetted Materials: Borosilicate glass, Teflon (PTFE, ECTFE)
Display: 10.4 inch diagonal, 800-600 pixels, color, Flat Panel Monitor with Resistant Touch Screen Interface, 200 bit brightness, gasketed for spill protection.
Air Supply: Integrated Air Compressor for U-Tube drying
Communication Interface: Touch Screen User Interface : 5 – USB Ports, 1 – Cat. 5 Port, 2 – RS232 Ports
Keyboard, Bar Code Scanner, Mouse, Network Capabilities
Video and Magnification: Video assisted view of cell, capable of approximately 10X magnification
Automatic Bubble Detection: Automatically warns operator of bubbles
Internal Memory: 8 GB Non-removable Compact Flash
Electrical Requirements :85 to 260 VAC; 48 to 62 Hz 150- 200 Watts
Dimensions lxwxh, cm :46.61 cm (L) x 29.97 cm (W) x 35.30 cm (H)
Shipping Information : Shipping Weight: 50 lbs. (23 kg)
